Weighing Accessories

These junction boxes are used to connect up to 4 load cells in parallel for connection to a single instrument.

• 4 Loadcell 4 wire Coupling Box
• IP67 sealing
• Polished Stainless steel construction
• Optional balancing resistors
• Optional 3 cell and Tachometer connection

These junction boxes are used to connect up to 4 load cells in parallel for connection to a single instrument.

• IP65 protection
• No additional internal wiring required
• PCB mounted terminals
• ABS housing

Six core screened, overall sheathed cable for use in weighing systems

• For use in weighing systems
• High noise immunity
• Suitable for hazardous areas (Blue)
• Fully compatible with all strain gauge load cells
• 6 core screened (3 twisted pairs)

• Sealed to IP65 for bottom glands, IP54 for top glands
• Analogue & serial input/output options
• Remotely programmable
• Panel, wall or suspension mounting
• Alpha-numeric display option
• DC power option

The Fusion Series is a range of smart, high visibility, high reliability LED displays, offering a wide choice of mounting methods, display colours and brightness levels.

These indicators are fully self-contained, incorporating wide ranging power supplies, precision signal conditioning, programme memory, display drivers, excitation supplies and serial communication interfaces.

Different models are available to cater for the measurement and display of process signals, totalisation, rate time, weight, serial remote display, etc.

As an optional extra, these displays can be connected onto an Ethernet network; Procon Engineers are available to discuss interfacing requirements for the purposes of Data Logging etc.

Model Numbers

• Fusion C – Counter/Rate
• Fusion L – Weight/Load
• Fusion P – Analogue Inputs 4-20mA/0 – 10 volt
• Fusion S – Serial Data

These are among the easiest of programmable panel meters to commission. They offer high precision with long-term reliability.

The Process Digital Display version accepts 4-20mA, 0-10V, 1-5V, 0-10mA input. It is ideal for all general-purpose process measurements such as weight, flow, pressure, level, humidity etc. 24V Excitation rated to 60mA. Last digit selectable to count by 1,2,5,10,20 or 50. Variable filtering / averaging. Remote logic inputs for tare (force to zero), reset, peak and valley. Rear panel security lock.

The Serial Digital Data Display version can be used as a slave indicator and for remote applications. It accepts RS232, RS422, RS485 and TTY in ASCII format. Addressable 00 to FF. Able to extract data from complex strings. 300, 600, 1200, 2400, 9600 baud rate.

• Front sealing to IP65
• Dual scale – imperial & metric
• Count by 1, 2, 5, 10, 20 or 50
• Analogue & serial output options
• Alarm output options
• 5 digit 14.2mm high red (or optional green} LED display

Used to apply a simulated load to enable verification of calibration and alarm trip functions. The LOSCAM is able to inject an offset signal (load offset) to simulate the crane lifting a real load. The load offset can be calibrated to exceed the crane SWL to enable load monitor alarm trips to be tested. Additionally, the LOSCAM is able to independently amplify and scale the load monitoring load cell signal to produce an isolated analogue signal suitable for connection to external monitoring data acquisition systems

• Rugged IP65 stainless steel enclosure
• Interface capability to Data Acquisition Systems
• Fully isolated 0-5V analogue output
• 24Vdca power supply
• Allows overload trip circuit checks
• System safe output
• Mains interference rejection filter
• Simulation of increased load

The LCS2 Load Cell simulator is a very useful device to have available when installing or servicing a weighing system. It can be used to isolate a fault to either the electronic weighing instrument or the load cells. It can also be used to simulate actual loads thereby enabling a batching sequence to be tested prior to connection to real plant load cells and actuators.

In-house or on-site simulation

• 0mV to 36mV output
• Excitation indicator
• Complete with plug in flying lead
• Polycarbonate enclosure
• Four cell simulation
