Load Cells

The 7188 is a high-performance shear beam load cell specifically designed for process weighing applications. Its fully welded stainless steel construction, along with a range of optional mounting accessories, makes the 7188 an ideal choice for demanding applications in almost any industry.

• Capacities from 500 to 20,000 kg
• Hermetically sealed
• Suitable for use in compression or tension
• All stainless steel construction
• ATEX Ex ia IIC T6 certified
• Bi-directional loading
• Wide range of mounting kits
• Low profile

The LP33 is a high-performance range of shear beam load cells specifically designed for process weighing applications. With a fully welded stainless steel construction and a wide range of optional mounting accessories, the LP33 is an ideal choice for demanding applications.

• Capacities from 500 to 40,000 kg
• IP67 stainless steel construction
• ATEX and OIML approved
• Range of mounting kits

The LP35 is fully welded and hermetically sealed to IP68 and IP69K as standard. It can, therefore, be used in the harshest industrial environments. Typical applications include weighing platforms, tank and vessel weighing, big bag (FIBC) filling systems, conveyors, and machinery with integrated weighing functions.

With a fully welded stainless steel construction and a wide range of optional mounting accessories, the LP35 is an ideal choice for demanding applications. It can be used with the patented LeverMount® and the LP35 anti-vibration mounting arrangement.

• Capacities from 300 to 10000 kg
• Hermetically sealed to IP68/69K
• Stainless steel construction
• Optional load feet and mounting accessories up to 5000 kg
• Calibrated in mV/V/Ώ
• Certified to OIML R60 3000d2
• Available with ATEX certification (see table overleaf)
• Parylene coating and high-temperature options up to 150°C (302°F)
• High integrity stainless steel cable entry

The LP20 is a fully welded stainless steel bending beam load cell that is hermetically sealed to IP68/IP69K and can be used in the harshest industrial environments. It is suitable for weighing platforms, bag fillers, belt weighers, and tank weighing in the food processing, chemical, pharmaceutical, and general bulk handling industries.

OIML C3 or C6-approved versions are available. A six-wire cable (with sense wires) is supplied as standard.

LP20 load cells are available with ATEX certification for all gas and dust zones. ATEX certification for dust zones 20, 21, and 22 does not require safety barriers, saving substantial costs.

For applications in aggressive environments where stress corrosion or acid attack is an issue, a special parylene coating can be specified as an option. High-temperature variants for continuous operation in environments up to 150°C (302°F) are also available.

• Capacities from 5 to 500 kg
• IP68/69K protection
• Hermetically sealed, fully welded construction
• Available in high-temperature versions
• Available with ATEX certification
• Stainless steel load sensor
• 3000 divisions OIML R60 Class C
• Option: 6000 divisions OIML R60 Class C
• Four-wire option available according to order

 The LP44 double-ended shear beam load cell, with its robust mounting accessory, is designed particularly for large silos and tanks and incorporates high anti-lift-off strength. It is also available with ATEX or IECEx certification and a high-temperature option. The mounting accessory’s mechanical characteristics have been designed and calculated using Eurocode 3 (EN 1993).

EN 1090 certification with CE marking is available on selected versions. Up to 75-tonne capacity jacking bolts are fitted to assist with installation and any routine maintenance. End-user industries include cement, food, minerals, chemicals, plastics, pharmaceuticals, paint, biomass, offshore, and utilities.

• Capacities from 2te to 200te
• Fully welded construction IP68/IP69K
• Stainless steel double shear beam load sensor
• Low profile
• High durability PU mud and chemical-resistant cable
• Resistant to off-axis loading
• Optional stainless steel mounting accessory
• Allows vessel expansion/contraction
• ATEX or IECEx certification for all zones

The LP50 is a high-capacity, low-profile compression load cell that can be used in force measurement and general weighing applications. For use in almost any industry, typical applications include rolling mills, test rigs, and heavy-duty weighing.

• Capacities 50, 100, 150, 200, 300, and 500 tonnes
• IP65 sealed
• Stainless steel element
• Low profile
• High-temperature option to 100°C (212°F)

Options available are:

• Plug and socket cable connection (recommended for 500Te load cells due to their size and weight to facilitate the safe handling and installation of the load cell)
• Custom build to customer’s specifications
• Cable length up to 25 m (82 ft) maximum

The LP72 stainless steel S-type tension load cell is ideal for “commercial” weighing due to its approval to OIML R60 3000 divisions (C3). Its fully welded and hermetically sealed construction ensures total environmental protection to IP68/IP69K, coupled with excellent long-term signal stability and performance. Additionally, it is supplied with a high-durability polyurethane cable and the option of rod end bearings, making the LP72 the ideal S-type load cell.

The LP72 load cell is available with optional ATEX certification for all gas and dust zones. The ATEX certification for dust zones 20, 21, and 22 does not require safety barriers, which saves substantial costs.

The optional high-temperature variant for continuous operation in environments up to 150°C (302°F) is also available.

For applications in aggressive environments where stress corrosion or acid attack is a potential problem, a special parylene coating can be specified as an option.

• Capacities from 250 kg to 7,500 kg
• Fully welded and hermetically sealed to IP68/IP69K
• Stainless steel load sensor
• Optional Ex and high-temperature versions
• 2 mV/V rationalised output
• Approved to 3000 divisions (C3) OIML R60 Class C
• High durability polyurethane cable
• Suitable for use in tension, compression, or a bi-directional manner
• Optional rod end bearings available
