Indicators and Controllers
Weighing indicators and batch controllers for versatile and fully controlled process systems
Our range of weighing indicators and batch controllers provide versatile and fully controlled process systems which enable complete plant control. Our systems have been designed to be integrated into current client systems and capable of meeting the expectations of numerous market sectors including food & beverage, chemical and general industrial applications where precision and accuracy are expected.
For full dimensions and specifications of each product, please use the Resources tab.
Type EP52 Batch and Process Weight Controller Spec Sheet
Type EP400 DIN-Rail Mount Digital Weight Indicator Spec Sheet
Type EP500 Panel Mount Digital Weight Indicator Spec Sheet
EP 1400 DIN-Rail Mount Digital Weight Indicator Spec Sheet
Type IT1 Weighing Terminal Spec Sheet
Type IT3 Weighing Terminal Spec Sheet
Type EP23 Weight Indicator Controller Spec Sheet
EP52 Batch & Process Controller
The EP52 Batch Controller is a versatile process control instrument capable of controlling a complete plant area. At the heart of the EP52 is a unique and powerful sequence control language designed to be easily programmed by plant engineers whilst maintaining the flexibility to meet the requirements of sophisticated control applications. Using a few straightforward commands the user can build a control sequence capable of managing a process all the way through to the final product. The EP52 is also available as a Loss of Weight or Beltweigher Controller using identical hardware.
- IP65 front panel
- Fully programmable high level sequence control language – on site
- Primary load cell, input with additional analogue process inputs and outputs option modules
- Integrate with PLC’s and SCADA systems
- 99 recipes – 16 ingredients user defined & named
- 114mm x 64mm backlit graphics and text display
- Ethernet IP & ProfiBus DP optional interfaces
- 2 programmable serial interfaces with various protocols including Modbus
EP 1400 DIN Rail Mount Weight Indicator
The EP 1400 weight transmitter is the perfect choice for hopper and vessel weighing applications. It delivers excellent weighing performance plus a host of useful communication features. These include a wide range of fieldbus protocols, available with serial output only or with serial and analogue outputs which means the EP 1400 can communicate with virtually any device.
The module is easy to install within equipment panels and can be mounted on a 35mm DIN Rail or OMEGA bar. The weight, the status of the instrument, the setting of parameters and any errors are all clearly shown on the display.
The fast 50 conversions per second ADC make it ideal for batching and dosing applications. Filtering can be adjusted to suppress signal fluctuations due to mechanical vibration, etc.
- USB port for easy computer connection
- Optional 0 – 5/10v and 4-20 m/A analogue output
- Five point linearization compensation
- Available with serial + analogue + any one of: Ethernet or Ethercat or Ethernet IP or DeviceNet or Profinet or Profibus DP or CANopen outputs
- High precision 24 bit analogue to digital conversion with 60,000 count resolution
- RS232, 422 or 485 serial port with ASCII or ModBus™ RTU
- Calibration and set-up via front panel or by PC with ‘Optimation’ software
EP500 Panel Mount Weight Indicator
A highly cost-effective weighing instrument for process vessel weighing and platform scales, the Type EP500 delivers excellent weighing performance plus a host of useful communication features. This combination makes it the perfect choice for hopper and vessel weighing applications where connectivity to PLCs and other types of control system is required.
The fast 50 conversions per second ADC make it ideal for batching and dosing applications. Filtering can be adjusted to suppress signal fluctuations due to mechanical vibration etc.
- 6 digit red LED 14mm high 7 segment display
- 50 conversions per second for quick update in dosing applications
- Ten-point linearisation compensation
- Optional 16-bit 4-20 mA analogue output
- Calibration and set-up via front panel or by PC with “innovation” software
- High precision 24 bit analogue to digital conversion with 60,000 count resolution
- RS232, 422 or 485 serial port with ASCII or ModBus RTU
- Two setpoint outputs (opto isolated)
- Optional Fieldbus connectivity with Profibus-DP, DeviceNet, TCP/IP and more
Type EP23 Weight Indicator / Controller
The EP23 Weight Indicator has been designed to be simple to configure. It is easy to set up because no menu is used.
The front panel has a 6 digit, 7-segment display window for displaying the measurement. It allows decimal point and minus sign characters to be included and has 4 alarm annunciators to show the status of each alarm relay.
The front panel push buttons each have a LED to show which setting is being altered.
The Weight Indicator / Controller can give alarm outputs, scaled and isolated analogue outputs and isolated serial data communication when fitted with option boards.
The EP23 is also available as a process display meter version, where the load cell input is replaced with either 4-20mA or 0-10V signal inputs.
- 4 relay trip outputs rated at 5A
- Analogue output options
- Optional IP65 front cover or wall mounting box
- 6-digit 20mm Red LED display (5 digit range)
- 10 point linearisation
- Optional serial interfaces – RS232 and RS485
